สินค้า
Thermowell for Thermometer, Flanged
Model: TWF
คำอธิบาย:
- Can be installed on bimetal thermometers, thermometer pointers, and thermocouples
- Suitable for high process and high chemical loads
- บริการตอบสนองหลังการขาย / การรับประกันที่ปรับแต่งได้ / คุณภาพสูง / การรับประกันหนึ่งปี
- ผลิตภัณฑ์จะถูกปรับแต่งตามความต้องการของคุณดังนั้นภาพผลิตภัณฑ์จึงมีการอ้างอิง
- Read more: The Accuracy Class and Limits of Error of Dial Thermometers
ดาวน์โหลดไฟล์
ข้อกำหนดผลิตภัณฑ์
左右尚有資訊
Version | Fabricated from pipe, machined from solid bar stock |
---|---|
Type | Straight, tapered, stepped |
Connection to thermometer | 1/4, 3/8, 1/2, 3/4 pt, g, npt, m |
Type of process connection | JIS, ANSI, DIN |
Nominal diameter | 1/2", 3/4", 1", 1 1/4", 1 1/2", 2", 3" |
Pressure rating | ANSI: 150, 300, 600LB... JIS: 5, 10, 16K... DIN: PN6, 10, 16... |
Thermowell | Material: 304 SS, 316 SS Length: can be customized Diameter: 9.5, 10, 12, 15 mm |
Accessories (option) | Coating, bushing |
